CLCH-SVX07C-EN 19
Unit Dimensions and Weights
Unit size 3 4 6 8 10 12 14 17 21 25 30
Humidifier
-Direct Steam
14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00
125.26 145.84 165.02 183.76 225.95 268.70 285.76 323.51 354.22 397.93 452.06
-Atmospheric
14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 19.00
126.77 167.88 177.85 203.32 252.08 276.18 311.72 338.64 396.01 432.20 527.53
Silencer
-3 ft
38.00 38.00 38.00 38.00 38.00 38.00 38.00 38.00 38.00 38.00 38.00
198.00 255.81 285.56 319.00 358.76 442.35 461.27 511.98 573.44 699.10 799.58
-5 ft
62.00 62.00 62.00 62.00 62.00 62.00 62.00 62.00 62.00 62.00 62.00
308.14 391.33 435.77 483.40 541.16 677.72 703.65 780.18 873.34 1072.96 1214.72
2-deck or 3-deck Multizone
- Horizontal discharge
n/a n/a 52.00 52.00 52.00 57.00 57.00 57.00 72.00 72.00 72.00
n/a n/a 521.86 581.76 672.98 751.82 795.28 829.01 1074.90 1130.69 1260.57
- Vertical discharge
n/a n/a 61.00 61.00 66.00 71.00 71.00 71.00 82.00 82.00 82.00
n/a n/a 615.93 676.27 832.69 922.38 966.31 1005.77 1228.90 1292.74 1418.36
UV light
14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00 14.00
76.02 93.64 98.69 120.26 135.22 146.68 155.07 162.95 179.84 188.71 218.33
Gas heat (highest MBH) n/a n/a
69.00 69.00 67.00 65.00 64.00 73.00 76.00 76.00 75.00
884.80 934.90 1042.60 1070.00 1089.00 1420.50 1294.80 1394.50 1477.70
Horizontal end cap
10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0 10.0
59.5 68.8 72.7 80.8 91.9 99.5 105.1 110.3 121.3 127.6 142.1
Diagonal economizer for
outdoor unit
45.50 49.00 49.50 48.00 53.00 53.00 56.50 52.00 62.50 57.00 62.50
203.89 247.13 270.83 289.91 348.65 378.29 425.94 431.12 554.51 565.16 689.49
Exhaust damper section for
outdoor unit
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
91.70 103.30 109.30 121.00 136.07 147.60 155.50 163.30 178.90 188.10 208.20
Hoods
- Side inlet hood (add to width) for
diagonal economizer
16.63 17.88 17.38 22.25 17.38 19.38 19.38 21.38 22.63 25.63 27.75
22.11 44.51 46.71 72.36 51.90 69.11 74.11 87.31 105.51 128.29 165.87
- Side inlet hood (add to width) for
mixing box
15.38 15.38 17.50 19.75 19.75 23.00 21.13 24.75 27.75 32.13 35.25
17.38 17.38 22.37 28.48 31.07 41.83 50.11 51.75 69.06 83.64 95.67
- Back inlet hood (add to length) for
mixing box
16.63 17.88 17.38 22.25 17.38 19.38 19.38 21.38 22.63 25.63 27.75
22.11 44.51 46.71 72.36 51.90 69.11 74.11 87.31 105.51 128.29 165.87
- Exhaust hood (add to length or
width)
15.38 15.38 17.50 19.75 19.75 23.00 21.13 24.75 27.75 32.13 35.25
12.36 12.36 15.95 20.47 21.26 29.08 29.65 34.70 45.03 58.67 67.02
Pipe cabinet weight
15 inches long, 36 inches deep 104.00 104.00 116.00 120.00 120.00 127.00 127.00 141.00 148.00 164.00 164.00
24 inches long, 36 inches deep 122.00 122.00 135.00 140.00 140.00 147.00 147.00 162.00 170.00 187.00 187.00
48 inches long, 36 inches deep 169.00 169.00 184.00 191.00 191.00 200.00 200.00 218.00 228.00 249.00 249.00
96 inches long, 36 inches deep 263.00 263.00 284.00 293.00 293.00 305.00 305.00 331.00 343.00 373.00 373.00
Table 4. Section dimensions (inches) and weights (pounds) - unit sizes 3-30
