20 CLCH-SVX07C-EN
Unit Dimensions and Weights
Notes: Add 0.19 inches to total unit length for each shipping split to account for gasketing.
Table 5. Section dimensions (inches) and weights (pounds) - unit sizes 35-120
Nominal airflow
1
17,500 20,000 25,000 28,500 33,000 40,000 50,000 60,000
Airflow at 625 fpm
2
23,263 25,519 34,375 39,581 47,225 53,475 65,106 76,388
Unit size 35 40 50 57 66 80 100 120
Height - indoor unit (in.)
3
67.25 67.25 75.75 85.50 92.50 107.50 119.75 119.75
Height - outdoor unit (in.)
4
includes base drip lip
76.075 76.075 85.45 95.20 102.20 117.20 129.45 129.45
Width (in.)
100.00 112.50 125.50 125.50 140.50 140.50 154.50 182.00
Weight add for outdoor unit
(lbs/in. of unit length)
3.02 3.28 3.74 6.13 2.88 2.88 3.11 3.55
Mixing box
-with or without angled filters
48.00 48.00 48.00 48.00 49.00 54.00 60.00 60.00
784.64 877.19 980.34 1055.78 1344.75 1501.00 1772.41 2016.97
-with top Traq dampers
48.00 48.00 48.00 48.00 84.00 92.00 96.00 96.00
917.88 1019.49 1188.45 1271.47 1812.46 2030.42 2313.89 2604.03
-with reduced length for airfoil
dampers only
35.50 38.50 41.50 41.50 41.50 41.50 47.00 53.00
635.84 716.69 845.71 845.71 1183.44 1272.94 1508.57 1773.61
Filters
-2-in. or 4-in. angled
24.50 24.50 27.50 27.50 27.50 27.50 27.50 27.50
533.86 580.66 676.42 704.29 882.20 945.62 1032.36 1136.60
-Cartridge (12-in.) or
short bag (18-in.)
24.50 24.50 27.50 27.50 27.50 27.50 27.50 27.50
428.04 438.45 549.07 566.64 775.99 807.31 927.71 1031.64
-2-in. or 4-in. flat
14.00 14.00 14.00 14.00 15.00 15.00 15.00 15.00
294.60 319.13 353.93 379.91 533.87 560.15 623.46 699.50
-2-in. and 4-in. combination flat
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
397.10 430.77 482.70 540.44 700.68 779.12 862.09 908.32
-Long bag (30-in.)
37.25 37.25 37.25 37.25 37.25 37.25 37.25 37.25
525.02 570.65 637.71 692.97 894.76 971.09 1061.74 1125.66
-Front-load
2-in or 4-in.flat, cartridge or HEPA
40.00 40.00 40.00 40.00 40.00 40.00 40.00 40.00
636.18 676.08 763.56 806.39 1031.28 1121.46 1250.59 1368.55
-Front-load Short Bag
45.00 45.00 45.00 45.00 45.00 45.00 45.00 45.00
684.89 727.15 821.08 867.34 1106.39 1201.85 1337.95 1461.13
Access or blank
5
-Small horizontal
10.00 10.00 10.00 10.00 n/a n/a n/a n/a
211.11 227.92 254.69 265.35 n/a n/a n/a n/a
-Medium horizontal
14.00 14.00 14.00 14.00 15.00 15.00 15.00 15.00
241.53 260.24 290.28 302.41 430.36 449.60 493.59 549.13
-Extended-medium horizontal
19.00 19.00 19.00 19.00 19.00 19.00 19.00 19.00
279.57 300.64 334.76 348.74 476.36 497.88 545.85 605.56
-Medium-large horizontal
24.50 24.50 24.50 24.50 24.50 24.50 24.50 24.50
267.55 289.53 324.20 337.75 475.62 497.08 547.88 613.24
-Large horizontal or turning
48.00 48.00 48.00 48.00 49.00 54.00 60.00 60.00
452.37 487.88 544.19 566.43 771.76 870.43 1036.54 1146.85
-Extra-large horizontal or turning
63.75 63.75 68.50 n/a n/a n/a n/a n/a
367.83 397.14 443.56 n/a n/a n/a n/a n/a
Note:
1
Nominal airflow is based on 500 fpm through a nominal coil (i.e. 500xunit size 8=4000 cfm).
2
Airflow@625 fpm through the flat filter (maximum
filter velocity).
3
Height includes standard 2.5-inch base frame for sizes 3-57 and 6-inch base frame for sizes 66-120.
4
Height includes 6-inch base
frame for sizes 3-120.
5
Variable lengths available from 14-96 inches.
6
Fan section weights include the heaviest fan with the largest ODP motor available.
7
Nominal length and height shown for discharge plenums. Variable plenum height and length is available from 0.5 to 1.5 of nominal.
