CLCH-SVX07C-EN 65
Component Installation Requirements
Table 11. Side Traq damper - standard flow mixing box
Unit
size
Damper
dia (in)
D a m p e r
qty
Damper torque
(in-lb.)
Total torque
(in-lb.)
Actuator torque
(max) (in-lb.) Actuator qty
Face-to-face
linkage
Linkage on
face
3 13.00 1 18.00 18.00 42 1 No No
4 13.00 1 18.00 18.00 42 1 No No
6 13.00 1 18.00 18.00 42 1 No No
8 13.00 1 18.00 18.00 42 1 No No
10 16.00 1 22.50 22.50 42 1 No No
12 16.00 1 22.50 22.50 42 1 No No
14 13.00 2 18.00 36.00 42 1 No Yes
17 13.00 2 18.00 36.00 42 1 No Yes
21 16.00 2 22.50 45.00 160 1 No Yes
25 16.00 2 22.50 45.00 160 1 No Yes
30 20.00 2 33.00 66.00 160 1 No Yes
35 20.00 2 33.00 66.00 160 1 No Yes
40 20.00 2 33.00 66.00 160 1 No Yes
50 24.00 2 36.00 72.00 160 1 No Yes
57 24.00 2 36.00 72.00 160 1 No Yes
66 24.00 2 36.00 72.00 160 1 No Yes
80 28.00 2 37.50 75.00 160 1 No Yes
100 28.00 3 37.50 112.50 160 1 No Yes
120 24.00 4 36.00 144.00 160 1 No Yes
Table 12. Side Traq damper - standard flow diagonal economizer
Unit
sizes
Damper
dia (in)
D a mpe r
qty
Damper
torque (in-lb.)
Total torque
(in-lb.)
Actuator torque
(max) (in-lb.)
Actuator
qty
Face-to-face
linkage
Linkage on
face
3 13.00 1 18.0 18.0 42 1 No No
4 13.00 2 18.0 36.0 42 2 No No
6 13.00 2 18.0 36.0 42 1 No Yes
8 13.00 2 18.0 36.0 42 1 No Yes
10 16.00 2 22.5 45.0 160 1 No Yes
12 16.00 2 22.5 45.0 160 1 No Yes
14 16.00 2 22.5 45.0 160 1 No Yes
17 13.00 4 18.0 72.0 160 1 No Yes
21 20.00 2 33.0 66.0 160 1 No Yes
25 16.00 4 22.5 90.0 160 1 No Yes
30 20.00 3 33.0 99.0 160 1 No Yes
35 28.00 2 37.5 75.0 160 2 No No
40 28.00 2 37.5 75.0 160 1 No Yes
50 24.00 3 36.0 108.0 160 1 No Yes
57 24.00 4 36.0 144.0 160 1 No Yes
66 28.00 3 37.5 112.5 160 1 No Yes
80 28.00 4 37.5 150.0 160 1 No Yes
100 28.00 5 37.5 187.5 160 2 No Yes
120 28.00 5 37.5 187.5 160 2 No Yes
