Trane TAM4A0C48S41SB User Manual

66 CLCH-SVX07C-EN
Component Installation Requirements
Table 13. Single -Side Traq low flow mixing box
Unit
size
Damper
Dia (in)
Damper
Qty
D a m p e r
Torque
(in-lb.)
Low flow
Traq Torque
(in-lb.)
Remained
Traq Torque
(in-lb.)
Actuator
qty for low
flow Traq
Actuator qty
for remained
damper
Actuator
total Qty
Face-to-
face
Linkage
Linkage
on Face
14 13.00 2 18.0 18.00 18.00 1 1 2 No No
17 13.00 2 18.0 18.00 18.00 1 1 2 No No
21 16.00 2 22.5 22.50 22.50 1 1 2 No No
25 16.00 2 22.5 22.50 22.50 1 1 2 No No
30 20.00 2 33.0 33.00 33.00 1 1 2 No No
35 20.00 2 33.0 33.00 33.00 1 1 2 No No
40 20.00 2 33.0 33.00 33.00 1 1 2 No No
50 24.00 2 36.0 36.00 36.00 1 1 2 No No
57 24.00 2 36.0 36.00 36.00 1 1 2 No No
66 24.00 2 36.0 36.00 36.00 1 1 2 No No
80 28.00 2 37.5 37.50 37.50 1 1 2 No No
100 28.00 3 37.5 37.50 75.00 1 1 2 No Yes
120 24.00 4 36.0 36.00 108.00 1 1 2 No Yes
Table 14. Dual-side Traq low flow mixing box
Unit
size
D a m p e r
dia (in)
Damper
qty
D a m p e r
torque
(in-lb.)
Low-flow
Traq torque
(in-lb.)
Remained
Traq torque
(in-lb.)
Actuator
qty for low-
flow Traq
Actuator qty
for remained
damper
Actuator
total qty
Face-to-
face
linkage
Linkage
on face
3 13.00 2 18.00 18.00 18.00 1 1 2 No No
4 13.00 2 18.00 18.00 18.00 1 1 2 No No
6 13.00 2 18.00 18.00 18.00 1 1 2 No No
8 13.00 2 18.00 18.00 18.00 1 1 2 No No
10 16.00 2 22.50 22.50 22.50 1 1 2 No No
12 16.00 2 22.50 22.50 22.50 1 1 2 No No
14 13.00 4 18.00 18.00 54.00 1 2 3 No No
17 13.00 4 18.00 18.00 54.00 1 2 3 No No
21 16.00 4 22.50 22.50 67.50 1 2 3 No No
25 16.00 4 22.50 22.50 67.50 1 2 3 No No
30 20.00 4 33.00 33.00 99.00 1 2 3 No No
35 20.00 4 33.00 33.00 99.00 1 2 3 No No
40 20.00 4 33.00 33.00 99.00 1 2 3 No No
50 24.00 4 36.00 36.00 108.00 1 2 3 No No
57 24.00 4 36.00 36.00 108.00 1 2 3 No No
66 24.00 4 36.00 36.00 108.00 1 2 3 No No
80 28.00 4 37.50 37.50 112.50 1 2 3 No No
100 28.00 6 37.5 37.5 187.5 1 2 3 No Yes
120 24.00 8 36.0 36.0 252.0 1 2 3 No Yes
