44
18-GJ89D1-1F-EN
MODEL TAMXB0C42CV41DB TAMXB0C48V41DB TAMXB0C60V51DB
RATED VOLTS/PH/HZ. 200 – 230/1/60 200 – 230/1/60 200 – 230/1/60
RATINGS
(a)
See O.D. Specifications See O.D. Specifications See O.D. Specifications
INDOOR COIL – Type
Plate Fin Plate Fin Plate Fin
Rows – F.P.I. 4 – 14 4 – 14 4 – 14
Face Area (sq. ft.)
5.04 5.96 5.96
Tube Size (in.)
3/8 3/8 3/8
Refrigerant Control
EEV EEV EEV
Drain Conn. Size (in.)
(b)
3/4 NPT 3/4 NPT 3/4 NPT
DUCT CONNECTIONS
See Outline Drawing See Outline Drawing See Outline Drawing
INDOOR FAN – Type Centrifugal Centrifugal Centrifugal
Diameter-Width (In.)
11 x 10 11 x 10 11 x 10
No. Used 1 1 1
Drive — No. Speeds
Direct – Variable Direct – Variable Direct – Variable
CFM vs. in. w.g.
See Fan Performance Table See Fan Performance Table See Fan Performance Table
No. Motors – H.P.
1 – 1/2 1 – 3/4
1 – 1
Motor Speed RPM
Variable ECM Variable ECM Variable ECM
Volts/Ph/Hz 208–230/1/60 208–230/1/60 208–230/1/60
F.L. Amps
(c)
3.0 — 4.1 5.0 — 6.1 6.4 — 7.5
FILTER
Filter Furnished? No No No
Type Recommended Throwaway Throwaway Throwaway
No.-Size-Thickness 1 – 22 x 20 – 1 in. 1 – 22 x 20 – 1 in. 1 – 22 x 20 – 1 in.
REFRIGERANT R-410A R-410A R-410A
Ref. Line Connections Brazed Brazed Brazed
Coupling or Conn. Size-in. Gas
7/8 7/8 7/8
Coupling or Conn. Size-in. Liq.
3/8 3/8 3/8
DIMENSIONS H x W x D H x W x D H x W x D
Crated (In.)
58 x 25.5 x 24.5 62.8 x 25.5 x 24.5 62.8 x 25.5 x 24.5
Uncrated 56.9 x 23.5 x 21.8 61.7 x 23.5 x 21.8 61.7 x 23.5 x 21.8
WEIGHT
Shipping (Lbs.)/Net (Lbs.)
162/150 174/162 175/163
(a)
These Air Handlers are AHRI certified with various Split System Air Conditioners and Heat Pumps (AHRI STANDARD 210/240).
(b)
3/4” Male Plastic Pipe (Ref.:ASTM 1785–76)
(c)
Check motor nameplate for actual FLA.
PPrroodduucctt SSppeecciiffiiccaattiioonnss
