Trane TAMXB0A24V21DB - Sensor

62
18-GJ89D1-1F-EN
ET / GT and Supply Air Temperature Sensor
Table 31. Thermal Resistance and Voltage Table
TEMP
F
TEMP C
THERMISTOR
RESISTANCE
(OHMS) *
Volts DC at plug
J3 EVAP TEMP
(ET) Orange to
Orange GAS TEMP
(GT) Black to
Black
TEMP
F
TEMP C
THERMISTOR
RESISTANCE
(OHMS) *
Volts DC at plug
J3 EVAP TEMP
(ET) Orange to
Orange GAS TEMP
(GT) Black to
Black
TEMP
F
TEMP C
THERMISTOR
RESISTANCE
(OHMS) *
Volts DC at plug
J3 EVAP TEMP
(ET) Orange to
Orange GAS TEMP
(GT) Black to
Black
20 –6.67 45075.79 1.89 64 17.78 13476.21 1.17 108 42.22 4752.65 0.50
21 –6.11 43763.76 1.88 65 18.33 13138.29 1.15 109 42.78 4649.14 0.49
22 –5.56 42494.36 1.88 66 18.89 12809.93 1.13 110 43.33 4548.19 0.48
23 –5.00 41266.06 1.87 67 19.44 12490.82 1.11 111 43.89 4449.73 0.47
24 –4.44 40077.41 1.86 68 20.00 12180.67 1.09 112 44.44 4353.70 0.46
25 –3.89 38926.99 1.85 69 20.56 11878.94 1.07 113 45.00 4260.02 0.45
26 –3.33 37813.46 1.84 70 21.11 11585.67 1.06 114 45.56 4168.63 0.44
27 –2.78 36735.53 1.83 71 21.67 11300.63 1.04 115 46.11 4079.48 0.43
28 –2.22 35691.94 1.82 72 22.22 11023.53 1.02 116 46.67 3992.49 0.42
29 –1.67 34681.49 1.81 73 22.78 10754.14 1.00 117 47.00 3907.61 0.41
30 –1.11 33703.02 1.79 74 23.33 10492.21 0.98 118 47.88 3824.78 0.40
31 –0.56 32755.43 1.78 75 23.89 10237.51 0.96 119 48.33 3743.96 0.40
32 0.00 31837.65 1.77 76 24.44 9989.83 0.95 120 48.89 3665.67 0.39
33 0.56 30948.64 1.75 77 25.00 9748.93 0.93 121 49.44 3588.08 0.38
34 1.11 30087.41 1.74 78 25.56 9514.63 0.91 122 50.00 3512.92 0.37
35 1.67 29253.02 1.72 79 26.11 9287.72 0.89 123 50.56 3439.56 0.36
36 2.22 28444.53 1.71 80 26.67 9064.99 0.88 124 51.11 3367.95 0.36
37 2.78 27661.07 1.69 81 27.22 8849.27 0.86 125 51.67 3298.03 0.35
38 3.33 26901.79 1.67 82 27.78 8639.38 0.84 126 52.22 3229.76 0.34
39 3.89 26165.86 1.66 83 28.33 8435.31 0.83 127 52.78 3163.10 0.34
40 4.44 25452.49 1.64 84 28.89 8236.36 0.81 128 53.33 3098.01 0.33
41 5.00 24760.93 1.62 85 29.44 8042.90 0.80 129 53.89 3031.44 0.32
42 5.56 24090.44 1.60 86 30.00 7854.60 0.78 130 54.44 2972.36 0.31
43 6.11 23440.31 1.58 87 30.56 7671.30 0.77 131 55.00 2911.73 0.31
44 6.67 22809.87 1.57 88 31.11 7492.86 0.75 132 55.56 2852.50 0.30
45 7.22 22198.45 1.55 89 31.67 7319.12 0.74 133 56.11 2794.65 0.30
46 7.78 21605.43 1.53 90 32.22 7149.96 0.72 134 56.67 2738.13 0.29
47 8.33 21030.19 1.51 91 32.78 6985.24 0.71 135 57.22 2682.92 0.28
48 8.89 20472.15 1.49 92 33.33 6824.82 0.69 136 57.78 2928.98 0.28
49 9.44 19930.75 1.47 93 33.89 6668.58 0.68 137 58.33 2576.27 0.27
50 10.00 19405.43 1.45 94 34.44 6516.41 0.67 138 58.89 2524.77 0.27
51 10.56 18895.66 1.43 95 35.00 6368.17 0.65 139 59.44 2474.44 0.26
52 11.11 18400.95 1.41 96 35.56 6223.77 0.64 140 60.00 2425.25 0.26
53 11.67 17920.80 1.39 97 36.11 6083.08 0.63 141 60.56 2377.18 0.25
54 12.22 17454.74 1.37 98 36.67 5946.01 0.61 142 61.11 2330.20 0.25
55 12.78 17002.31 1.35 99 37.22 5812.44 0.60 143 61.67 2284.27 0.24
56 13.33 16563.08 1.33 100 37.78 5682.28 0.59 144 62.22 2239.38 0.24
57 13.89 16136.61 1.31 101 38.33 5555.43 0.58 145 62.78 2195.49 0.23
58 14.44 15622.51 1.29 102 38.89 5431.80 0.56 146 63.33 2152.59 0.23
59 15.00 15320.36 1.27 103 39.44 5311.29 0.55 147 63.89 2110.64 0.22
60 15.56 41929.80 1.25 104 40.00 5193.82 0.54 148 64.44 2069.63 0.22
61 16.11 14550.46 1.23 105 40.56 5079.31 0.53 149 65.00 2029.52 0.21
62 16.67 14181.97 1.21 106 41.11 4967.66 0.52 150 65.56 1990.31 —
63 17.22 13824.00 1.19 107 41.67 4858.80 0.51
Values should be within +/- 5%
