Trane TAMXB0A24V21DB - Heater Attribute Data

18-GJ89D1-1F-EN
51
Heater Attribute Data
Note: Heater size will be announced when using the resistor that is being provided with the BAYEA heater. Heater can also be configured in the
UX360 User Interface or Diagnostics Mobile App.
TAMXB0A24V21DB
Heater Model No.
No. of
Circuits
240 Volt 208 Volt
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater Amps
per Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater 0 - - 4.1 ** 5 15 - - 4.1 ** 5 15
BAYEAAC04++1 1 3.84 13100 16.0 25 25 2.88 9800 13.8 22 25
BAYEAAC05++1 1 4.80 16400 20.0 30 30 3.60 12300 17.3 27 30
BAYEAAC08++1 1 7.68 26200 32.0 45 45 5.76 19700 27.7 40 40
BAYEAAC10++1
(a)
1 9.60 32800 40.0 55 60 7.20 24600 34.6 48 50
BAYEAAC10LG3 1-3 PH 9.60 32800 23.1 34 35 7.20 24600 20.0 30 30
Note: ** Motor Amps
(a)
Heater not qualified for 208V when installed in horizontal left position without Heat Pump
TAMXB0B30V31DB
Heater Model No.
No. of
Circuits
240 Volt 208 Volt
Capacity
Heater
Amps
per
Circuit
Minimum
Circuit
Ampaci-
ty
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater 0 - - 4.1 ** 5 15 - - 4.1 ** 5 15
BAYEAAC04++1 1 3.84 13100 16.0 25 25 2.88 9800 13.8 22 25
BAYEAAC05++1 1 4.80 16400 20.0 30 30 3.60 12300 17.3 27 30
BAYEAAC08++1 1 7.68 26200 32.0 45 45 5.76 19700 27.7 40 40
BAYEAAC10++1 1 9.60 32800 40.0 55 60 7.20 24600 34.6 48 50
BAYEAAC10LG3 1-3 PH 9.60 32800 23.1 34 35 7.20 24600 20.0 30 30
BAYEABC15LG3 1-3 PH 14.40 42000 34.6 48 50 10.80 36900 30.0 43 45
BAYEABC15BK1 - Circuit 1
(a)
BAYEABC15BK1 - Circuit 2
2
9.60 32800 40.0 55 60 7.20 24600 34.6 48 50
4.80 16400 20.0 25 25 3.60 12300 17.3 22 25
Note: ** Motor Amps
(a)
MCA and MOP for circuit 1 contains the motor amps
TAMXB0C36V31DB
Heater Model No.
No. of
Circuits
240 Volt 208 Volt
Capacity
Heater
Amps
per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
kW BTUH kW BTUH
No Heater 0 - - 4.1 ** 5 15 - - 4.1 ** 5 15
BAYEAAC04++1 1 3.84 13100 16.0 25 25 2.88 9800 13.8 22 25
BAYEAAC05++1 1 4.80 16400 20.0 30 30 3.60 12300 17.3 27 30
BAYEAAC08++1 1 7.68 26200 32.0 45 45 5.76 19700 27.7 40 40
BAYEAAC10++1 1 9.60 32800 40.0 55 60 7.20 24600 34.6 48 50
BAYEAAC10LG3 1-3 PH 9.60 32800 23.1 34 35 7.20 24600 20.0 30 30
BAYEABC15LG3 1-3 PH 14.40 42000 34.6 48 50 10.80 36900 30.0 43 45
