Trane Tracer AdaptiView User Manual

64
CTV-SVU01G-EN
Table 18. Compressor settings and status points (Simplex) (continued)
Oil Tank Pressure
Lube Pump Command (CVHS)
Oil Tank Temperature Lube Flow First Stage Bearing (CVHS)
Inboard Bearing Temperature Lube Flow Second Stage Bearing (CVHS)
Outboard Bearing Temperature Outboard Bearing Pad Temperature #1 (CVHH Only)
IGV 1 Percent Open Outboard Bearing Pad Temperature #2 (CVHH)
IGV 1 Position (Steps) Outboard Bearing Pad Temperature #3 (CVHH)
Table 19. Motor settings and status points (Simplex)
Active Current Limit Setpoint (button links to Active Current Limit
Setpoint screen)
AFD Motor Current U % RLA
Average Motor Current (%RLA)
AFD Motor Current V % RLA
ADF Frequency or Generator Frequency Command (based on
configuration)
AFD Motor Current W % RLA
Starter Motor Current L1 (%RLA)
AFD Motor Current U
Starter Motor Current L2 (%RLA)
AFD Motor Current V
Starter Motor Current L3 (%RLA)
AFD Motor Current W
Starter Motor Current L1 (A) AFD Input Current L1
Starter Motor Current L2 (A) AFD Input Current L2
Starter Motor Current L3 (A) AFD Input Current L3
Starter Input Voltage Phase AB AFD Average Motor Voltage
Starter Input Voltage Phase BC AFD Average Input Voltage
Starter Input Voltage Phase CA AFD Motor Voltage UV
Motor Winding Temp 1 AFD Motor Voltage VW
Motor Winding Temp 2 AFD Motor Voltage WU
Motor Winding Temp 3 AFD DC Bus Voltage
AFD Speed
AFD DC Bus Current
AFD Transistor Temp AFD Calculated Input Voltage
Starter Energy Consumption Resettable AFD Output Power
Starter Energy Consumption Last Reset AFD Average Input Current
Starter Energy Consump Non Reset Motor Speed
Starter Power Demand
Motor Frequency
Starter Load Power Factor
Table 20. Purge settings and status points (Simplex)
Purge Top Level Mode (button links to Purge Operating Modes screen Pumpout Chiller On—7 days
Purge Regen Cycle (button links to Purge Regen Cycle screen) Pumpout Chiller Off—7 days
Purge Fault Indicator (button links to Alarms screen) Time Until Next Purge Run
Daily Pumpout—24 Hours Purge Rfgt Compressor Suction Temp
Average Daily Pumpout—7 Days Purge Liquid Temperature
AAppppeennddiixx AA:: DDaattaa ffoorr CCeennTTrraaVVaacc SSiimmpplleexx CChhiilllleerrss
