Data Points in Custom Data Graphs
Table 44. Evaporator
Active Chilled Water Setpoint Approx Evap Water Flow
Evaporator Leaving Water Temperature Evap Differential Wtr Press
Evaporator Entering Water Temperature Calculated Chiller Capacity
Evap Sat Rfgt Temp Evap Approach Temp
Evap Rfgt Pressure Active Ice Termination Setpoint
Table 45. Compressor
Chiller Control Signal Inboard Bearing Temp
Oil Tank Pressure
Outboard Bearing Temp
Oil Pump Discharge Pressure Outboard Bearing Pad Temperature #1
Oil Differential Pressure
Outboard Bearing Pad Temperature #2
Lube Pump Suction Pressure
(CVHS)
Outboard Bearing Pad Temperature #3
Lube Pump Discharge Pressure
(CVHS)
IGV1 Position (%)
Lube Differential Pressure
(CVHS)
IGV2 Position (%)
Oil Tank Temperature Compressor Refrigerant Discharge Temperature
Lube Flow First Stage Bearing
(CVHS)
Compressor Vibration
Lube Flow Second Stage Bearing
(CVHS)
Table 46. Condenser
Active Hot Water Setpoint Cond Approach Temp
Cond Leaving Water Temp Approx Cond Water Flow
Cond Entering Water Temp
Cond Differential Wtr Press
Cond Sat Rfgt Temp Second Condenser Lvg Wtr Temp
Outdoor Air Temp Second Condenser Ent Wtr Temp
Refrigerant Monitor Differential Refrigerant Pressure
Cond Rfgt Pressure
Head Pressure Control Status
Table 47. Motor
Active Current Limit Setpoint AFD Input Current L1
Average Motor Current %RLA AFD Input Current L2
Motor Frequency AFD Input Current L3
Speed Command
(CVHS)
AFD Input Frequency
Starter Motor Current L1 % RLA
AFD Average Motor Voltage
Starter Motor Current L2 % RLA
AFD DC Bus Voltage
Starter Motor Current L3 % RLA AFD DC Bus Current
AAppppeennddiixx AA:: DDaattaa ffoorr CCeennTTrraaVVaacc SSiimmpplleexx CChhiilllleerrss
