Trane Tracer AdaptiView User Manual

CTV-SVU01G-EN
81
Table 58. ASHRAE Chiller Log data (continued)
Data name Value
Refrigerant Monitor XXX.X ppm
Active Chilled Water Setpoint
XXX.X F°/C°
Active Current Limit Setpoint
XXX.X %
Cond Entering Water Temp
XXX.X °F/C°
Cond Leaving Water Temp
XXX.X °F/C°
Cond Water Flow Status
Flow/No Flow
Cond Differential Wtr Press
XXX.X PSI/kPa
Approx Cond Water Flow XXXX gpm/lpm
Top Level Operating Mode (Ckt1 and Ckt2) Dependent on chiller type
Evaporator Saturated Rfgt Temp (Ckt1 and Ckt2)
XXX.X °F/C°
Evaporator Refrigerant Pressure (Ckt1 and Ckt2)
XXX.X PSI/kPa
Evaporator Approach Temp (Ckt1 and Ckt2)
XXX.X °F/C°
Condenser Saturated Rfgt Temp (Ckt1 and Ckt2)
XXX.X °F/C°
Condenser Refrigerant Pressure (Ckt1 and Ckt2)
XXX.X PSI/kPa
Condenser Approach Temperature (Ckt1 and Ckt2)
XXX.X °F/C°
Compressor Starts (Ckt1 and Ckt2)
XXXX
Compressor Running Time (Ckt1 and Ckt2)
XX:XX Hr:Min
Compressor Refrigerant Discharge Temperature (Ckt1 and Ckt2)
XXX.X °F/C°
Oil Pump Discharge Pressure (Ckt1 and Ckt2)
XXX.X PSI/kPa
Oil Tank Pressure (Ckt1 and Ckt2)
XXX.X PSI/kPa
Oil Differential Pressure (Ckt1 and Ckt2)
XXX.X PSI/kPa
Oil Tank Temperature (Ckt1 and Ckt2)
XXX.X °F/C°
Inboard Bearing Temp (Ckt1 and Ckt2)
XXX.X °F/C°
Outboard Bearing Temp (Ckt1 and Ckt2)
XXX.X F°/C°
Daily Pumpout—24 Hrs (Ckt1 and Ckt2)
XXX.X Min
Daily Pumpout Limit (Ckt1 and Ckt2)
XXX.X Min
Pumpout—Life (Ckt1 and Ckt2)
XXXXXX.X Hours
Purge Top Level Mode (Ckt1 and Ckt2) On/Auto/Adaptive/Stop
Purge Operating Mode (Ckt1 and Ckt2) On/Auto/Adaptive/Stop
Starter Current L1 (Ckt1 and Ckt2)
XXXX A
Starter Current L2 (Ckt1 and Ckt2)
XXXX A
Starter Current L3 (Ckt1 and Ckt2)
XXXX A
Starter Voltage Phase AB (Ckt1 and Ckt2)
XXXX V
Starter Voltage Phase BC (Ckt1 and Ckt2)
XXXX V
Starter Voltage Phase CA (Ckt1 and Ckt2)
XXXX V
AAppppeennddiixx BB:: DDaattaa ffoorr CCeennTTrraaVVaacc DDuupplleexx CChhiilllleerrss
