Table 78. Compressor (continued)
Outboard Bearing Pad Temperature #3 Ckt2
*Added for CDHH
IGV 1 Percent Open Ckt2
IGV 1 Position Ckt2
IGV 2 Percent Open Ckt2
IGV 2 Position Ckt2
Compressor Rfgt Discharge Temp Ckt2
Table 79. Motor
Active Current Limit Setpoint
Motor Frequency Ckt1
Frequency Command Ckt1
Average Motor Current % RLA Ckt1
Starter Motor Current L1 % RLA Ckt1
Starter Motor Current L2 % RLA Ckt1
Starter Motor Current L3 % RLA Ckt1
Starter Motor Current L1 Ckt1
Starter Motor Current L2 Ckt1
Starter Motor Current L3 Ckt1
Starter Average Phase Voltage Ckt1
Starter Input Voltage AB Ckt1
Starter Input Voltage BC Ckt1
Starter Input Voltage CA Ckt1
Motor Winding Temperature 1 Ckt1
Motor Winding Temperature 2 Ckt1
Motor Winding Temperature 3 Ckt1
Motor Temperature Ckt1
Starter Input Power Consumption Ckt1
Starter Power Demand Ckt1
Starter Motor Power Factor Ckt1
AFD Average Input Current Ckt1
AFD Input Current L1 Ckt1
AFD Input Current L2 Ckt1
AFD Input Current L3 Ckt1
AFD Input Frequency Ckt1
AFD Output Voltage Ckt1
AFD DC Bus Voltage Ckt1
AFD DC Bus Current Ckt1
(Note: Added per CR 51244, 5/2/14)
