Communication with other controllers
CNT-SVX05B-EN 5
Figure 2. Tracer AH540 termination board
Analog outputs:
AO1–AO5
Binary inputs: IN7–IN12
Binary outputs:
BO1–BO6
Not used
Not used
Not used
AC power
Analog inputs:
IN1–IN6
Duct static pressure
Comm5 terminals
