Chapter 5 Configuration
80 CNT-SVX05B-EN
Table 48. Supply fan status ignore time configuration
Parameter Valid range Default value
Fan status ignore time
1
0.0 to 6,553 seconds 45 seconds
1 This configuration property defines the maximum period of time the supply fan status binary input is ignored after the control
has started the supply fan.
Table 49. Face-and-bypass damper heat modulation setpoint configuration
Parameter Valid range Default value
Heat modulation setpoint 14 to 122°F (-10 to 50°C) 40°F (4.4°C)
Note: This parameter is only used when a face-and-bypass damper is present. When the outdoor air temperature is below this outdoor-
air-temperature setpoint, the face-and-bypass damper is used to modulate the hydronic heat capacity. When the outdoor air temperature
rises to 3°F (1.67°C) above this setpoint, the heat valve is used to modulate the hydronic heat capacity.
Table 50. Freeze avoidance setpoint configuration
Parameter
Valid range
1
Default value
Freeze avoidance setpoint
2
32 to 122°F (0 to 50°C) 35°F (1.67°C)
1 A freeze avoidance setpoint value outside the valid range disables the freeze avoidance function.
2 This setpoint defines the outdoor air temperature with which the controller initiates the freeze avoidance function.
Table 51. Freeze avoidance valve configuration
Parameter Valid range Default value
Time period 0 to 120 minutes 20 minutes
Duty cycle
1
0 to 100% 50%
Valve open position
2
0 to 100% 50%
1 Duty cycle is the percentage of the time period the steam valve is open.
2 The steam valve open position can be set to a partially open position to prevent excessive steam coil temperatures.
Table 52. Entering water temperature sampling configuration
Parameter Valid range Default value
Time period between sampling cycles 60 to 1440 minutes 120 minutes
Maximum sampling time
1
90 to 3600 seconds 180 seconds
Ignore time
2
0 to 30 seconds 60 seconds
Valve position during sampling 0 to 100% 50%
1 The controller will sample the entering water temperature for this amount of time, after the ignore time.
2 The entering water will not be sampled until ignore time has expired, allowing the water valve time to open and establish flow.
