Trane Tracer CH530 User Manual

DynaView Interface
15RLC-SVU05A-E4
Chiller Level Mode
Top Level Mode Description
Shutting Down
The chiller is still running but shutdown is imminent. The chiller is going through a compressor run-
unload or extended operational pumpdown of the lag circuit/compressor (or all circuits
simultaneously).
Shutting Down Sub Modes Description
Operational Pumpdown
The lag circuit (or all circuits) is in the process shutting down by performing an operational pumpdown
just prior to stopping the circuit's compressor. The EXV is commanded closed. Pumpdown will
terminate when both the liquid level and the evap pressure are low (below specific criteria) or after a
specific time has expired.
Evaporator Water Pump Off Delay: MIN:SEC
The Evaporator water pump is continuing to run past the shutdown of the compressors, executing the
pump off delay timer.
Cond Water Pump Off Delay: MIN:SEC
The Condenser water pump is continuing to run past the shutdown of the compressors, executing the
pump off delay timer.
Chiller Level Mode
Top Level Mode Description
Misc.
These sub modes may be displayed in most of the top level chiller modes
Misc. Sub Modes Description
Manual Evap(orator)* Water Pump Override The Evaporator water pump relay is on due to a manual command.
Diagnostic Evap Water Pump Override The Evaporator water pump relay is on due to a diagnostic.
Diagnostic Cond Water Pump Override The Condenser water pump relay is on due to a diagnostic.
Local Schedule Active
The local time of day scheduler (option) is operational and could automatically change modes or
setpoints as scheduled
Manual Condenser Water Pump Override The condenser water pump relay is on due to a manual command.
Manual Compressor Control Signal Chiller capacity control is being controlled by DynaView or TechView.
Night Noise Setback
The Night Noise Setback feature has been activated. If the unit is running, fans will be running at low
speed.
Hot Water Control
These modes are mutually exclusive and they indicate that the chiller is controlling to the active hot
water setpoint, the active chilled water setpoint, or the active ice termination setpoint respectively.
Chilled Water Control
Ice Building

Trane Tracer CH530 Specifications

General

Series	Tracer CH530
Input Voltage	24 VAC
Communication Protocols	BACnet, LonWorks
Compatibility	Trane
Product Type	Chiller controller
Memory	Flash memory for program storage
Dimensions	Varies depending on the specific model and enclosure. (Example: Approximately 250mm x 200mm x 100mm)
Weight	Varies by configuration
