Trane Tracer CH530 User Manual

DynaView Interface
RLC-SVU05A-E416
Table 2 - Circuit Level Operating Modes
Circuit Level Mode
Top Level Mode Description
Stopped
The circuit is not running, and cannot run without intervention.
Stopped Sub Modes Description
Diagnostic Shutdown - Manual Reset The circuit has been shutdown on a latching diagnostic.
Front Panel Circuit Lockout
The circuit is manually locked out by the circuit lockout setting - the nonvolatile lockout setting is
accessible through either the DynaView or TechView.
External Circuit Lockout The respective circuit is locked out by the external circuit lockout binary input.
Circuit Level Mode
Top Level Mode Description
Run Inhibit
The given circuit is currently being inhibited from starting (and running), but may be allowed to start if
the inhibiting or diagnostic condition is cleared.
Run Inhibit
Sub Modes
Description
Diagnostic Shutdown - Auto Reset The circuit has been shutdown on a diagnostic that may clear automatically.
Low Oil Flow Cool Down Time mn:sc The cool-down period is necessary to allow the compressor rotors to cool after starts.
Restart Inhibit min:sec
The compressor (and therefore, its circuit) is currently unable to start due to its restart inhibit timer. A
given compressor is not allowed to start until 5 minutes (adj) has expired since its last start, once a
number of "free starts" have been used up.
Circuit Level Mode
Top Level Mode Description
Auto
The circuit is not currently running but can be expected to start at any moment given that the proper
conditions are satisfied.
Auto Sub Modes Description
Calibrating EXV
This submode is displayed when the EXV is performing a calibration. A calibration is only performed
when the chiller is not running and never more frequently than once every 24 hours
Circuit Level Mode
Top Level Mode Description
Waiting to Start
The chiller is going through the necessary steps to allow the lead circuit to start.
Waiting to Start
Sub Modes
Description
Start Inhibited Waiting For Oil
The compressor (and thus its circuit) will wait up to 2 minutes in this mode for oil level to appear in the
oil tank.
Waiting For EXV Preposition
The Chiller will wait for the time it takes the EXV to get to its commanded pre-position prior to starting
the compressor. This is typically a relatively short delay and no countdown timer is necessary (less
than 15 seconds)

Trane Tracer CH530 Specifications

General

Series	Tracer CH530
Input Voltage	24 VAC
Communication Protocols	BACnet, LonWorks
Compatibility	Trane
Product Type	Chiller controller
Memory	Flash memory for program storage
Dimensions	Varies depending on the specific model and enclosure. (Example: Approximately 250mm x 200mm x 100mm)
Weight	Varies by configuration
