Trane Tracer CH530 User Manual

DynaView Interface
7RLC-SVU05A-E4
The second screen (Figure 3) will
display for 15-25 seconds. If a valid
configuration is present, "Tracer
CH530" will also be displayed. If the
MP configuration is found to be
invalid, "MP: Invalid Configuration"
is displayed indefinitely. Contact
your local Trane service technician.
Figure 3
Figure 4
The third screen is the first screen
of the application.

Trane Tracer CH530 Specifications

General

Series	Tracer CH530
Input Voltage	24 VAC
Communication Protocols	BACnet, LonWorks
Compatibility	Trane
Product Type	Chiller controller
Memory	Flash memory for program storage
Dimensions	Varies depending on the specific model and enclosure. (Example: Approximately 250mm x 200mm x 100mm)
Weight	Varies by configuration
