Chapter 1 Overview and specifications
4 CNT-SVX06B-EN
Additional components
The Tracer ZN511 zone controller may require the use of additional com-
ponents for monitoring and proper control of the associated fan coil or
heat pump. Using these components depends on the application. They are
not included with the Tracer ZN511 zone controller.
Power transformer
A transformer providing 24 Vac is required to power the Tracer ZN511
zone controller and associated output relays and valve and damper actua-
tors.
Zone temperature sensors
Table 1 shows the Trane zone temperature sensors that are supported by
the Tracer ZN511 zone controller.
Water and duct temperature sensors
Temperature sensors must be Trane 10 kΩ (at 25°C) thermistors. Enter-
ing water (fan coil), leaving water (heat pump), and discharge air inputs
may use a sealed temperature sensor (part number 4190 1100).
Binary input switching devices
Occupancy, condensate overflow, and low-temperature inputs accept
switching devices that may have normally open or normally closed dry
contacts.
Table 1. Tracer zone temperature sensor options
BAS order
number
Use
Fan Zone
Timed
override
buttons
Comm
jack
High Med Low Auto Off
Set-
point
thumb-
wheel
Te m p e -
ature
sensor
On
Can-
cel
4190 1087 Any x
4190 1088 Any x x x x
4190 1090 Heat pump x x x x x
4190 1094 Heat pump x x x
4190 1095 Unit vent x x x x x x x x
4190 1115Fan coil xxxxx x x x x x
4190 1116 Unit vent x x x x x x x x x
4190 1117 Any x x x x x x x
