CNT-SVX06B-EN 11
Chapter 3
Mounting the controller
This chapter gives recommendations and requirements for mounting the
Tracer ZN511 zone controller.
Location recommendations
For fan coil applications, the controller can usually be mounted inside the
end pocket of the unit. For heat pump applications, the controller should
be mounted on the side of the unit. Trane recommends locating the
Tracer ZN511 zone controller:
• Near the controlled piece of equipment to reduce wiring costs
• Where it is easily accessible for service personnel
• Where public access is restricted to minimize the possibility of tam-
pering or vandalism
Operating environment requirements
Operate a Tracer ZN511 zone controller in an indoor environment that
meets the following requirements:
• Temperature: 32°F to 140°F (0°C to 60°C)
• Relative humidity: 5–95%, noncondensing
