64 RT-SVX21N-EN
Unit Wiring Diagrams Numbers
Note: Wiring diagrams can be accessed using e-Library
by entering the diagram number in the literature
order number search field or by contacting
technical support.
Table 17. Unit wiring diagram numbers
Schematic Type Drawing Number Description
Control
ReliaTel™
230,460,575V
4366-7217 YHC(037-067)
4366-4571 Y(S,H)C(036,048)E/F, ReliaTel Controls, X13 IDM
4366-1015 Y(S,H)C(036-090)E/F, ReliaTel Controls, Belt-Drive IDM
4366-4703 Y(S,H)C060E/F, ReliaTel Controls, X13 IDM
4366-1042 YSC(092,102)F, ReliaTel Controls
4366-7436 (YHC092-102,YSC120)F, ReliaTel Controls
4366-7430 YHC120E, ReliaTel Controls
Electromechanical
4366-8386
Y(S,H)C(036,048)E/F, Electromechanical Controls, X13
IDM
4366-8383
Y(S,H)C(036-060)E/F, Electromechanical Controls,
Belt-Drive IDM
4366-8387 Y(S,H)C060E/F, Electromechanical Controls, X13 IDM
4366-8385 Y(S,H)C(072,090)F, Electromechanical Controls
4366-8384 YSC(092,102)F, Electromechanical Controls
4366-8388 (YHC092-102,YSC120)F, Electromechanical Controls
4366-8395 YHC120E, Electromechanical Controls
Schematic Type Drawing Number Description
Power
ReliaTel™
230V
4366-7179 YHC(037-067) (230V)
4366-4576 Y(S,H)C(036-060)E/F (1-Phase)
4366-5163 YHC(036-060)E/F (230V 3-Phase), X13 IDM
4366-1016 Y(S,H)C(036-090)E/F (230V 3-Phase), Belt-Drive IDM
4366-1033 YSC(092,102)F (230V)
4366-7437 (YHC092-102, YSC120)F (230V), ReliaTel Controls
4366-7430 YHC120E, ReliaTel Controls
460V and/or 575V
4366-7180 YHC(037-067) (460V)
4366-5164 YHC(036-060)E/F (460V), X13 IDM
4366-1005 Y(S,H)C(036-090)E/F (460V,575V), Belt-Drive IDM
4366-1034 YSC(092,102)F (460V,575V)
4366-7438 (YHC092-102, YSC120)F (460V), ReliaTel Controls
4366-7439 YSC120F (575V), ReliaTel Controls
4366-7430 YHC120E, ReliaTel Controls
Electromechanical
230V
4366-6406 YHC(092-120)E, Electromechanical Controls
4366-6449 YHC(092-102)F, YSC120F, Electromechanical Controls
460V and/or 575V
4366-6406 YHC120E, Electromechanical Controls
4366-6436 YHC(092-102)F4, Electromechanical Controls
4366-6782 YSC(120)FW, Electromechanical Controls
Schematic Type Drawing Number Description
Connection ReliaTel™ 230V
4366-7340 YHC(037) (230V)
4366-8247 YHC037E (230V), 17 Plus with Multi-Zone VAV
4366-7342 YHC(047-067) (230V)
4366-8249 YHC(047, 067)E (230V), 17 Plus with Multi-Zone VAV
4366-4564 Y(S,H)C(036,048)E/F (1-Phase), ReliaTel Controls
4366-5185
YHC(036,048)E/F (230V 3-Phase), ReliaTel Controls,
X13 IDM
4366-1522
Y(S,H)C(036-060)E/F (230V 3-Phase), ReliaTel
Controls, Belt-Drive IDM
4366-4705 Y(S,H)C060E/F (1-Phase), ReliaTel Controls
4366-5186 YHC060E/F (230V 3-Phase), ReliaTel Controls, X13 IDM
4366-1539 Y(S,H)C(072,090)F (230V), ReliaTel Controls
4366-7449 YHC120E (3-Phase), ReliaTel Controls
