Transducer Techniques DPM-3 User Manual

- 19 -
12. TEDS SIGNAL CONDITIONER WITH NON-TEDS TRANSDUCERS
MENU
KEY
DIGIT SELECT
KEY
VALUE SELECT KEY
InPut
Input signal
type
_Strn_
Load cells. Factory de-
fault scaling is 50 mV FS
__20.0 __50.0 _100.0 _250.0 _500.0
20, 50, 100, 250, 500 mV full scale.
_dC u
DC millivolts
SEtuP
Meter Setup
00_00
Display type
0 4-1/2 digit meter, counts by 1
1 5-digit remote display (±99,999)
2 4-1/2 digit meter, counts by 10
3 3-1/2 digit meter
00 _00
Power line frequency
0 Noise minimized for 60 Hz
1 Noise minimized for 50 Hz
_0_00
Meter scaling method
0 Scale and offset method
1 Coordinates of 2 points method
2 Reading coordinates of 2 points method
00_00
Rear connector control
inputs 1 & 2
True = logic 1 (0V or
tied to digital ground)
False = 0 (5V or open)
0 1 = Reset, 2 = Meter Hold
1 1 = Function Reset 2 = Pk or Valley Disp.
2 1 = Meter Hold 2 = Pk or Valley Disp.
3 1 = Meter Hold 2 = Tare
4 1 = Peak or Valley 2 = Tare
5 1 = Tare 2 = Reset
6 1 = 0, 2 = 0, decimal point 1= XXXXX
1 = 1, 2 = 0, decimal point 1 = XXXX.X
1 = 0, 2 = 1, decimal point 1 = XXX.XX
1 = 1, 2 = 1, decimal point 1 = XX.XXX
7 1 = 0, 2 = 0, decimal point 2 = XXXX.X
1 = 1, 2 = 0, decimal point 2 = XXX.XX
1 = 0, 2 = 1, decimal point 2 = XX.XXX
1 = 1, 2 = 1, decimal point 2 = X.XXX.X
8 1 = Function Reset 2 = Display Blank
9 1 = Hold 2 = Display Blank
A 1 = Peak or Valley 2 = Display Blank
B 1 = Tare 2 = Display Blank
C 1 = Valley Display 2 = Peak Display
D 1 = Tare 2 = Tare Reset
Both control inputs 1 & 2 set to 1 for selections
2, 4, A, C = Function Reset.
Both control inputs 1 & 2 set to 1 for selections
0, 1, 3, 5, 8, 9, B, D = Meter Reset.
