Transducer Techniques DPM-3 User Manual

- 20 -
MENU
KEY
DIGIT SELECT
KEY
VALUE SELECT KEY
ConFG
Meter
Configuration
000_0
Operation as a rate of
change meter.
Extended meter only.
0 Not rate of change
1 Rate x 0.1
2 Rate x 1
3 Rate x 10
4 Rate x 100
5 Rate x 1000
6 Rate x 10000
000_0
Operation of front panel
PEAK button and rear
connector for Peak or
Valley Display
0 Peak Display. Also selects “Peak” in
“Peak or Valley” at connector above.
1 Valley Display. Also selects “Valley” in
“Peak or Valley” at connector above.
2 Peak (1st push), Valley (2nd push)
000_0_
Signal polarity.
0 Normal signal polarity
1 Reverse signal polarity
000_0_
Nonlinear input scaling
Extended meter only..
0 Linear input
1 Custom curve linearization
FiLtr
Filtering
00000
Alarm filtering
0 Alarm unfiltered
1 Alarm filtered
00000
Peak & Valley filtering
0 Peak & Valley unfiltered
1 Peak & Valley filtered
00000
Display filtering
0 Display batch average every 16 readings
1 Display filtered signal
00000
Adaptive filter threshold
0 Low adaptive filter threshold level
1 High adaptive filter threshold level
00000
Input signal filtering.
Can be applied to dis-
play, setpoint, analog
output, data output.
0 Autofilter
1 Batch average, 16 readings
2 Moving average, 0.08 sec.
3 Moving average, 0.15 sec.
4 Moving average, 0.3 sec.
5 Moving average, 0.6 sec.
6 Moving average, 1.2 sec.
7 Moving average, 2.4 sec.
8 Moving average, 4.8 sec.
9 Moving average, 9.6 sec.
A Unfiltered
dEc.Pt
Dec. point
selection
d.dddd
Decimal point flashes.
d.dddd dd.ddd ddd.dd dddd.d ddddd.
.ddddd
