- 21 -

KEY

DIGIT SELECT

KEY

VALUE SELECT KEY

Scaling method “Scale and Offset” if selected under SEtuP

SCALE

Scale factor

0.0000 0.0000 0.0000

Select digit to flash.

Select -9 thru 9 for flashing first digit, 0 thru 9

for other flashing digits. Select decimal point

location when decimal point is flashing.

OFFst

Offset value

0.0000 0.0000 0.0000

0.0000 0.0000

Select digit to flash.

Select -9 thru 9 for flashing first digit, 0 thru 9

for other flashing digits. Decimal point location

is selected by dEC.Pt.

Scaling method “Coordinates of 2 points” if selected under SEtuP

Lo In.

Low signal

input.

0.0000 0.0000 0.0000

0.0000 0.0000

Select digit to flash.

Select -9 thru 9 for flashing first digit, 0 thru 9

for other flashing digits. Decimal point is set by

input range chosen.

Lo rd

Desired read-

ing at Lo In.

0.0000 0.0000 0.0000

0.0000 0.0000

Select digit to flash.

Select -9 thru 9 for flashing first digit, 0 thru 9

for other flashing digits. Decimal point is set by

dEC.Pt.

Hi In.

High signal

input.

0.0000 0.0000 0.0000

0.0000 0.0000

Select digit to flash.

Select -9 thru 9 for flashing first digit, 0 thru 9

for other flashing digits. Decimal point is set by

input range chosen.

Hi rd.

Desired read-

ing at Hi In.

0.0000 0.0000 0.0000

0.0000 0.0000

Select digit to flash.

Select -9 thru 9 for flashing first digit, 0 thru 9

for other flashing digits. Decimal point is set by

dEC.Pt.

Scaling method “Reading coordinates of 2 points” if selected under SEtuP

Lo In.

Low signal

input.

_0.021

Apply a low reference

signal to the meter.

_0.021

Press to store the low signal input in the

meter.

Hi In.

High signal

input.

_20.094

Apply a high reference

signal to the meter.

_20.094

Press to store the high signal input in the

meter.

Lo rd

Desired read-

ing at Lo In.

0.0000 0.0000 0.0000

0.0000 0.0000

Select digit to flash.

0.0000

Select -9 thru 9 for flashing first digit, 0 thru 9

for other flashing digits. Decimal point is set by

dEC.Pt.

Hi rd.

Desired read-

ing at Hi In.

0.0000 0.0000 0.0000

0.0000 0.0000

Select digit to flash.

6.7500

Select -9 thru 9 for flashing first digit, 0 thru 9

for other flashing digits. Decimal point is set by

dEC.Pt.
