Transducer Techniques DPM-3 - Page 26

- 26 -
KEYSTROKES FOR SETPOINT SETUP
If the MENU key does not work, see Section 8 “Enabling & Locking Out Menu Items.”
MENU KEY
DIGIT SELECT
KEY
VALUE SELECT KEY
ALSEt
Alarm Setup for
relays 1 & 2 if
detected.
Press until
ALSEt is displayed.
00000
Relay state when
alarm is active.
0 Relay 1 on Relay 2 on
1 Relay 1 off Relay 2 on
2 Relay 1 on Relay 2 off
3 Relay 1 off Relay 2 off
00000
Alarm latching or non-
latching (auto reset).
0 Alarm 1 auto reset Alarm 2 auto reset
1 Alarm 1 latching Alarm 2 auto reset
2 Alarm 1 auto reset Alarm 2 latching
3 Alarm 1 latching Alarm 2 latching
00000
Alarm operates at and
above setpoint (active
high) or at and below
setpoint (active low).
0 AL1 active high AL2 active high
1 AL1 active low AL2 active high
2 AL1 disabled AL2 active high
3 AL1 active high AL2 active low
4 AL1 active low AL2 active low
5 AL1 disabled AL2 active low
6 AL1 active high AL2 disabled
7 AL1 active low AL2 disabled
8 AL1 disabled AL2 disabled
00000
Hysteresis mode or
band deviation mode
0 AL1 band deviation AL2 band deviation
1 AL1 hysteresis AL2 band deviation
2 AL1 band deviation AL2 hysteresis
3 AL1 hysteresis AL2 hysteresis
4 No deviation or hysteresis in menu.
00000
Number of consecutive
readings in alarm zone
to cause an alarm.
0 After 1 reading 4 After 16 readings
1 After 2 readings 5 After 32 readings
2 After 4 readings 6 After 64 readings
3 After 8 readings 7 After 128 reading
ALS34
Alarm Setup for
relays 3 & 4 if
detected.
00000
Relay state when
alarm is active.
0 Relay 3 on Relay 4 on
1 Relay 3 off Relay 4 on
2 Relay 3 on Relay 4 off
3 Relay 3 off Relay 4 off
00000
Alarm latching or non-
latching (auto reset).
0 Alarm 3 auto reset Alarm 4 auto reset
1 Alarm 3 latching Alarm 4 auto reset
2 Alarm 3 auto reset Alarm 4 latching
3 Alarm 3 latching Alarm 4 latching
