- 27 -
ALS34
Alarm Setup for
relays 3 & 4
(continued)
00000
Alarm operates at and
above setpoint (active
high) or at and below
setpoint (active low).
0 AL3 active high AL4 active high
1 AL3 active low AL4 active high
2 AL3 disabled AL4 active high
3 AL3 active high AL4 active low
4 AL3 active low AL4 active low
5 AL3 disabled AL4 active low
6 AL3 active high AL4 disabled
7 AL3 active low AL4 disabled
8 AL3 disabled AL4 disabled
00000
Hysteresis mode or
band deviation mode
(see Glossary)
0 AL3 band deviation AL4 band deviation
1 AL3 hysteresis AL4 band deviation
2 AL3 band deviation AL4 hysteresis
3 AL3 hysteresis AL4 hysteresis
00000
Number of consecutive
readings in alarm zone
to cause an alarm.
0 After 1 reading 4 After 16 readings
1 After 2 readings 5 After 32 readings
2 After 4 readings 6 After 64 readings
3 After 8 readings 7 After 128 reading
0.0000 0.0000 0.0000
0.0000 0.0000
Select digit to flash.
Select -9 thru 9 for flashing first digit, 0 thru 9
for other flashing digits. Alarms will activate
above the setpoint by the value entered and
deactivate below the setpoint by the value
entered.
DEU1b Alarm 1
band deviation
0.0000 0.0000 0.0000
0.0000 0.0000
Select digit to flash.
Select -9 thru 9 for flashing first digit, 0 thru 9
for other flashing digits. Alarms will activate
above and below the setpoint by the value
entered and will deactivate in the middle of
the band.
DEU2b Alarm 2
band deviation
0.0000 0.0000 0.0000
0.0000 0.0000
Select digit to flash.
Select -9 thru 9 for flashing first digit, 0 thru 9
for other flashing digits. Alarms will activate
above the setpoint by the value entered and
deactivate below the setpoint by the value
entered.
DEU3b Alarm 3
band deviation
0.0000 0.0000 0.0000
0.0000 0.0000
Select digit to flash.
Select -9 thru 9 for flashing first digit, 0 thru 9
for other flashing digits. Alarms will activate
above and below the setpoint by the value
entered and will deactivate in the middle of
the band.
DEU4b Alarm 4
band deviation
To Next Page
