Transducer Techniques SSI User Manual

- 33 -
SEr_1 Serial Config 1
Fixed Parameters:
No parity
8 data bits
1 stop bit
* Filtered is not available for
Fast conversion rates.
000 Sent value
source
0 Unfiltered* 1 Filtered
000 Serial baud rate
0 300 baud 4 4800 baud
1 600 baud 5 9600 baud
2 1200 baud 6 19.2 kbaud
3 2400 baud 7 38.4 kbaud
000 Output rate
Rates shown are for 60
Hz. Divide by 1.2 for 50
Hz. Selection 0 is line
frequency. Selection 1
is normal display
interval.
0 60 / sec 8 1 / 34 sec
1 3.8 / sec 9 1 / 68 sec
2 1.9 / sec A 1 / 137 sec
3 0.94 /sec B 1 / 273 sec
4 1 / 2.1 sec C 1 / 546 sec
5 1 / 4.3 sec D 1 / 1092 sec
6 1 / 8.5 sec E 1 / 2185 sec
7 1 / 17 sec F 1 / 4369 sec
SEr_2 Serial Config 2
000_ <LF> character
0 No <LF> following <CR>
1 <LF> following <CR>
000_ Serial alarm
data
0 No alarm data appended
1 Alarm data appended
000_ Operating mode
0 Continuous mode
1 Command mode
SEr_3 Serial Config 3
00 Serial
termination characters
for multiple items
0 At end of all items.
1 At end of each item. If Alarm
data, only at end.
00 Serial data sent
0 Reading
1 Peak
2 Valley
3 Reading + Peak
4 Reading + Valley
5 Reading + Peak + Valley
6 Displayed Value
