Setup Manual - Butler S2
System messages
L O A d
»LOAd« Butler S2 is in bootloader mode. This display may result
from an incomplete firmware update or when the system button
is pressed while powering up the Butler S2.
C r d
»Crd« Card error, the microSD card is missing, a le is corrupt
or a read error occured. Press the button, if the error reap-
pears rewrite the card.
S E r
»SEr« Serial number error. The reading of the serial number
failed. Repower system. If the error reappears contact your
e:cue service.
r E S
The Butler S2 executes a soft reset after the System button was
pressed for at least four seconds.
Power supply
The Butler S2 can be powered by an external AC/DC power supply or via Power-
over-Ethernet (PoE). The power supply must deliver a supply current of 250 mA.
Only use the e:cue power supply. The PoE supply voltage is 48 V DC. Power-over-
DMX is not supported.
When using Power-over-Ethernet do not connect any power supply
physically to the DC Input of the Butler S2. Otherwise the power feed
from Ethernet will not be recognized.
e:net
Use standard CAT5 (RJ45) network cabling for e:net.
Please remember that e:net requires an isolated network segment
and cannot operate properly when using e.g. internet or video/audio
streaming in the same network simultaneously.
