Setup Manual - Butler S2
Butler S2 in the Network tab with a small asterisks. This helps to identify the
Butler S2 in a Butler Garage or in a huge configuration. Additionally the assigned
Action is triggered.
In standalone mode and during normal operation
• When pressed for a short time (less than six seconds) the Butler S2 executes the
Action assigned to the system button. See the Lighting Application Suite System
Manual for a detailed list of assignable Actions.
• Keeping the button pressed for more than six seconds a fast blinking r E S gets
displayed. If the button is released now a soft reset is executed and the Butler S2
returns to normal operation.
• Keeping the button pressed for more than 12 seconds a fast blinking d E F is
displayed. Releasing the button now resets the configuration of the Butler S2 to
factory settings. This includes the IP, which is then 192.168.123.1 again.
• If you keep the button pressed for more than 18 seconds no changes are made.
In standalone mode and in an error condition
• A short press acknowledges the error and restarts the system.
microSD card
The Butler S2 comes with a microSDHC card. The Butler S2 cannot operate if no
microSD card is present. As a typical show file and configuration files do not take
up more than a few Megabytes space, it is generally not necessary to replace the
provided microSD card with a bigger one. If the microSD card has been removed
during operation and is restored, the show may be continued by pressing the but-
ton on the device – otherwise you need to reboot.
Do not remove the SD card while the Butler S2 is in operation!
