Setup Manual - Butler S2
Technical Data
General data
Dimensions
(W x H x D)
71.5 x 24 x 85 mm/
2.7 x 0.9 x 3.6 inch (w/o power plug)
Weight 125 g
Power 12 … 24 VDC via ext. PSU
48 V DC via PoE
Rated current max. 250 mA
Power consumption 2.7 W (incl. DMX termination)
Operating/storage temp. 0 … 40 °C/32 … 104 °F
Operating/storage humidity 0 … 80% non-condensing
Protection class IP20
Electrical safety SELV
Materials Aluminium, plexi glass, steel
Mounting Desktop or in Butler Garage
Certification CE
Interfaces
Operator display 7-segment LED
2 x e:net status LEDs
Control keys 1 x Push button
e:net/Ethernet 1 x RJ45, 10/100 MBit, PoE enabled
Supply power 2 x Screw terminals, cable width 0.25 … 1 mm²
DMX/RDM 2 x RJ45, USITT DMX512-A/RDM E1.20
Electrically isolated up to 1000 V
Conforms to UL Std. UL 60950-1
Cert. to CSA Std. C22.2 No. 60950-1
