NX-Platform Hardware Installation and Safety 27
Important: Hot-swapping a 40GbE I/O module with another 40GbE I/O module is fully supported.
However, a full reboot is required under the following conditions:
• If you insert a 40GbE module into a slot which previously did not have a 40GbE module
• If you remove a 40GbE module from a slot and then insert a different module type that is not another
40GbE module
For a list of transceivers supported on NX-Platform device modules, refer to the TippingPoint Operating System
(TOS) Release Notes Version 3.9.0.
NX-Platform devices support the following standard I/O modules:
Module name Ports Port speed Part number
6-Segment Gig-T NX (Gig-T) 12 Copper 10/100/1000
Mbps
TPNN0059
6-Segment GbE SFP NX (SFP) 12 SFP 1Gbps TPNN0068
4-Segment 10GbE SFP+ NX (SFP+) 8 Fiber 10Gbps TPNN0060
