TRENDnet TDM-C500 - ATM Settings

18
; Default Route: Click the radio button to “Enable” or “Disable” the Default Route
functionality.
Configuration Procedure:
1. From the WAN – Channel Config page, click and select 1483 Routed connection mode from the
Channel Mode drop down manual. The default 1483 Routed connection setup is displayed.
2. Under the Channel mode, enter the values of VPI and VCI settings.
3. Click the radio button and elect the Encapsulation type ( LLC or VC-Mux).
Note: Your ADSL service provider or your ISP will supply these. In this case the ADSL service
provider is using LLC.
4. Check the radio button to “Enable” or “Disable” the NAPT setting. Leave as its default setting if your
ADSL provider or ISP didn’t provide any setting information.
Note: NAPT: Network Address and Port Translation: An extension of NAT, NAPT maps many
private internal addresses into one IP address. The outside network (WAN) can see this one
IP address but it cannot see the individual device IP addresses translated by the NAPT.
5. Under the WAN IP mode, enter the “Local IP Address”, “Subnet Mask”, “Remote IP Address” and
“DNS” setting if you are using the Fixed IP (Or Static IP) mode. These information/data will be provided
by your ADSL Service provider or ISP.
6. Check the radio button to “Enable” or “Disable” the Default Route setting. Leave as its default setting
if your ADSL provider or ISP didn’t provide any setting information.
7. Click “Add” button after setup.
8. You can “Edit” (
) or “Delete” ( ) the existing connection profile under the Actions column.
9. Click “Admin/ Commit/Reboot”. Press “Commit” to save the settings into flash memory.
10. The new settings will take effect after reboot the system.
11. The following window display indicates the system restarting process.
12. The following screen display after the system rebooting process. The System Home page will shows all
the connection status and system information.
ATM Settings
The page is for ATM PVC QoS parameters setting.
Fields in this page:
Field Description
VPI
Virtual Path Identifier. This is read-only field and is selected on the Select column in
the Current ATM VC Table.
VCI
Virtual Channel Identifier. This is read-only field and is selected on the Select column
in the Current ATM VC Table. The VCI, together with VPI, is used to identify the next
destination of a cell as it passes through to the ATM switch.
QoS Quality of Server, a characteristic of data transmission that measures how accurately
