Connection through Ethernet Cable
Following are the steps to properly connect your TDM-C500 ADSL2/2+ Modem Router by Ethernet
Cable (RJ-45):
1. Turn off your computer/notebook.
2. Connect the ADSL port of your TDM-C500 ADSL2/2+ Modem Router to the wall jack of the
ADSL/ADSL2/ADSL2+ Line with a RJ-11 cable.
3. Connect the Ethernet cable (RJ-45) from your TDM-C500 ADSL2/2+ Modem Router to the
Ethernet Adaptor in your computer.
4. Connect the Power adaptor to the TDM-C500 ADSL2/2+ Modem Router and plug it into a Power
outlet.
5. Turn on your computer.
6. Refer to the next section to setup or configure your system’s Network Adaptor.
The Power light will be on after turning on the TDM-C500 ADSL2/2+
Modem Router.
!
Use the Power Adaptor exclusively in combination with the equipment
supplied and do not use any other kind of power adaptor for the
equipment.
!
