TRENDnet User’s Guide
Industrial Managed Switch Series
20
Basic Settings
General Settings
System
Management VLAN
To specify a VLAN group which can access the Switch.
 The valid VLAN range is from 1 to 4094.
 If you want to configure a management VLAN, the management VLAN should
be created first and the management VLAN should have at least one member
port.
Host Name
The hostname is same as the SNMP system name. Its length is up to 64 characters.
The first 16 characters of the hostname will be configured as the CLI prompt.
Default Settings
The default Hostname is [YOUR_DEVICE_NAME]
The default DHCP client is disabled.
The default Static IP is 192.168.10.200
Subnet Mask is 255.255.255.0
Default Gateway is 0.0.0.0
Management VLAN is 1.
CLI Commands
Node
Command
Description
configure
Reboot
This command reboots the system.
configure
hostname STRINGS
This command sets the system's network
name.
configure
interface eth0
This command enters the eth0 interface
node to configure the system IP.
eth0
Show
This command displays the eth0
configurations.
eth0
ip address A.B.C.D/M
This command configures a static IP and
subnet mask for the system.
eth0
ip address default-
gateway A.B.C.D
This command configures the system
default gateway.
eth0
ip dhcp client
(disable|enable|renew)
This command configures a DHCP client
function for the system.
Disable: Use a static IP address on the
switch.
Enable & Renew: Use DHCP client to get an
IP address from DHCP server.
eth0
management vlan
VLANID
This command configures the management
vlan.
Example: The procedures to configure an IP address for the Switch.
 To enter the configure node.
[DEVICE_NAME]#configure terminal
[DEVICE_NAME](config)#
 To enter the ETH0 interface node.
[DEVICE_NAME](config)#interface eth0
[DEVICE_NAME](config-if)#
 To get an IP address from a DHCP server.
[DEVICE_NAME](config-if)#ip dhcp client enable
 To configure a static IP address and a gateway for the Switch.
[DEVICE_NAME](config-if)#ip address 192.168.202.111/24
[DEVICE_NAME](config-if)#ip address default-gateway 192.168.202.1
