Multicast
• IGMP snooping v1, v2, v3
• Static multicast address
• Up to 256 multicast entries
Special Features
• CLI & web based management
• Full power PoE+
• Wide operating temperature range
• Dual redundant power inputs
• Alarm relay triggered by power failure
• Surge/ESD protection
Power
• PWR (Primary) terminal input: 48 – 57V DC (TI-S12048 sold separately)
• RPS (Redundant) terminal input: 48 – 57V DC (TI-S12048 sold separately)
• Consumption: 10 W (max.), 130 W (max.) with PoE+ fully loaded
Optional Power Adapter (48VDC3000 sold separately)
• Input: 100 - 240 V AC, 50/60 Hz, 2 A
• Output: 48 V DC, 3.34 A 160 watts max.
Optional Power Supply (TI-S24048 sold separately)
• Input: 100-240 V AC, 50/60 Hz, 1.8 A 125-370 V DC
• Output: 240 Watts, 48 V, 5 A
• DIN-rail: TS-35/7.5 or 15
• Operating Temperature: - 25 to 70 °C (- 13 to 158 °F)
PoE
• PoE budget: 120W
• Up to 15W per port for PoE
• Up to 30W per port for PoE+
• Mode A: Pins 1, 2 (V+) and pins 3, 6 (V-)
• PoE enable/disable per port setting, priority, scheduling, power delay, and PD
alive check
Enclosure
• IP30 rated metal enclosure
• DIN-Rail Mount
• Grounding Point
• ESD (Ethernet) Protection: 8KV DC
• Surge (Power) Protection: 6KV DC
MTBF
• 180,136 hrs @ 65 °C
• 435,905 hrs @ 25 °C
Operating Temperature
• - 40 – 70 °C (- 40 - 158 °F)
Operating Humidity
• Max. 95% non-condensing
Dimensions
• 135 x 120 x 31 mm (5.31 x 4.72 x 1.22 in.)
Weight
• 528 g (1.17 lbs.)
Certifications
• CE
• FCC
• Shock (IEC 60068-2-27)
• Freefall (IEC 60068-2-32)
• Vibration (IEC 60068-2-6)
