4.4.- Oil installation
The TRO Evolution System boiler is supplied with a Domestic gas-oil burner (10) (see model in
Technical Characteristics). To install the oil line, proceed in accordance with the burner
instructions enclosed with this manual (see Burner section). The oil line installation and start-up
of the burner must be carried out by qualified, authorised personnel.
4.5.- Combustion products exhaustion
The installation of exhaustion of the products of combustion has to be carried out by
qualified personnel staff and it will fulfill the requirements demanded in the legislation and
effective regulatory schemes.
The TRO Evolution System boilers are balanced flue oil boilers, so that the combustion
products exhaustion is carried out by means of an outlet duct and an air intake from outside.
It is recommended that the position at the exhaustion duct exterior portion should be in
accordance with the data of the following figures and table:
Position of the exhaustion duct
Minimum
distance
mm
A under a cornice 300
B between two horizontally-arranged ducts 1000
C from a next window 400
D between two vertically-arranged ducts 1500
E from a next venting grid 600
F under a balcony (*) 300
G under a window 600
H under a venting grid 600
I from a break back of a building 300
J from an angle of a building 300
K from the floor level 2500
L from a vertically/horizontally-arranged outlet or pipe (**) 300
M from a front surface at a distance of 3 metres from the exhaust gas outlet 2000
N like the previous one, but with opening 3000
(*) In so far the balcony width does not exceed 2000 mm.
(**) If the pipe constructive materials were sensitive to the action from the flue gases, this distance
should be longer than 500 mm.
ATTENTION: All the fittings used in the combustion products exhaustion and air intake are to
be those supplied by TRIANCO firm.
