Trilogy Orator - Bit;S Link

Orator Installation Guide
Page 16 of 37 Issue 2 Trilogy Broadcast Limited
Orator
3.3.5 20M bit/S Link
Connector type: 9 way D type fixed plug
Pin Function
1 Error Out
6 CPU Analyse
2 N Test
7 N Reset
3 Ground
8 From PC-
4 From PC+
9 To PC-
5 To PC+
