1. INTRODUCTION
This manual provides installation information for the Orator Digital Intercom system. Cabling
and pin-out information is included for all of the Trilogy manufactured items plus some
commonly used third party equipment. Other information relating to the hardware
configuration will be useful if the system is upgraded or expanded in the future.
Ø Section 2 covers the matrix assembly and installation, to the point where the matrix may
be powered
Ø Section 3 covers all of the cabling necessary to complete the installation.
Ø Section 4 gives wiring details for the range of Trilogy control panels.
Ø Section 0 provides Information on installing other equipment (e.g. telephones, radio
talkback).
For further assistance please contact Trilogy Broadcast Projects Department at the address
given at the front of this document. You may also contact us by e-mail at:
projects@trilogy-broadcast.co.uk
1.1 Options Available and Module Type Numbers
Contact Sales Department for a listing of the current module types.
Due to the nature of talkback systems, any given installation may have some custom parts.
Trilogy Broadcast Ltd. prides itself on its ability to tailor standard parts to meet specific
requirements and is willing to discuss any other customisation as required.
