5. OTHER EQUIPMENT
5.1 Belt Boxes
Belt Boxes may be connected to the Orator matrix, on ports configured as 4 wire. They
require an external voltage supply, either +15V or µ 15V depending on the type number. If
the belt-boxes have been supplied as part of the initial system, then an external voltage
connector will have been fitted to the Orator power supply. The tables below show the
different types available.
Type No. of
input
channels
#
Fixed Connector
type
Mating Connector
type required
Voltage
required
410-50-02 1 XLR6 Male XLR6 Female +15V
410-50-03 2 Hirose 12 Way Plug
RM15TRD-12P
Hirose 12 Way Socket
RM15TPD-12S
± 15V
410-50-04 3 Hirose 12 Way Plug
RM15TRD-12P
Hirose 12 Way Socket
RM15TPD-12S
± 15V
# All Belt Boxes have one output channel.
The following tables give individual connector pin-outs for each type.
410-50-02 Single Channel Belt Box
Connector Pins Function
1,2 (+,-) Audio from box
3,4 (+,-) Audio to box
5 0V
6 +15V
410-50-03 Two Channel Belt Box
Connector Pins Function
1 Chassis
2,3 (+,-) Audio 1 to box (PTB)
4,5 (+,-) Audio 2 to box (Prog Snd)
6,7 (+,-) Audio from box
8 +15V
9 -15V
10 OV to box
11,12 (+,-) N/c
410-50-04 Three Channel Belt Box
Connector Pins Function
1 Chassis
2,3 (+,-) Audio 1 to box (PTB)
4,5 (+,-) Audio 2 to box (Prog Snd)
6,7 (+,-) Audio from box
8 +15V
9 -15V
10 0V to box
11,12 (+,-) Third audio to box
