4. CONTROL PANELS
All control panels connect to the matrix in point to point topology. Each panel utilises a single
matrix port, although expansion panels may be connected to a single “master” panel using
the expansion in and expansion out connectors fitted on the rear of the panel. Two standard
panels may be linked together, for example to provide 48 keys for an operator, but only
utilising a single matrix port. A series of additional connectors provide the following facilities,
on the panel types indicated in the table.
Comprehensive audio inputs and outputs
√ √ √
Expansion ports 1 2 2
Local logic inputs and outputs
√
Test Port for re-programming
√ √ √ √
Remote control footswitches
√
4.1 Standard Control Panels
The following detail refers to these panel types:
Ø 500-30-30 24 key panel
Ø 500-31-30 16 key panel
Ø 500-31-31 16 key panel with dial pad
Ø 500-32-30 8 key panel
Ø 500-32-31 8 key panel with dial pad
Dimensions 485mm wide x 88.9mm high x 80mm deep
(max, excluding connectors). Approx. 110mm
deep ( max including mating connectors)
19” x 2RU rack mounting
Mains Input 90 – 250 V ac, 50-60Hz
Current Consumption 150-50 mA
Details of panel connections are provided in the following tables. Other features may be
enabled or disabled by the DIP switches accessible at the top of the panel. These are
detailed in section 4.1.3.
