Pin Input/Output Function
J1P1 Input (-)
Bank C-D Unlock
Ground this input to unlock compartment Banks C
and D.
J1P2 Input (-)
Bank A-B Unlock
Ground this input to unlock compartment Banks A and
B.
J1P3 Input (-)
Compartment Door Ajar
Ground this input to indicate any of the compartment
doors are ajar.
J1P4 & J1P16 Input Vehicle Ground
J1P5 & J1P17 (Relay 30A)
Bank D Lock
30A max relay output
J1P6 & J1P18 (Relay 30A)
Bank D Unlock
30A max relay output
J1P7 & J1P19 Input Vehicle Battery—Powers relays
J1P8 (Relay 20A)
Entry Door Unlock
20A max relay output.
J1P9 Input (-)
Unlock Entry
Ground this input to unlock the entry door.
J1P10 Input (-)
Unlock All
Ground this input to unlock the entry door and all
compartment doors in Banks A-D.
J1P11 Input (-)
Lock All
Ground this input to lock the entry door and all com-
partment doors in Banks A-D.
J1P12 Input (-)
Lock Entry
Ground this input to lock the entry door.
J1P13 Input (-)
Security
Ground this input to indicate a break in and activate.
J1P14 (Unused Pin)
J1P15 (Unused Pin)
J1P20 (Unused Pin)
J1P21 (Relay 20A)
Entry Door Lock
20A max relay output.
J1P22 (Unused Pin)
J1P23 Input (-)
Entry Door Ajar
Ground this input to indicate any of the entry doors
are ajar.
J1P24 (Relay 20A)
Dome Light
20A max relay output.
J1—Main Chassis Connector 24-Pin
16
Note: Grounding J1P1 and J1P2 together will unlock banks A-D in order.
