Pairing FOB
You will need to have access to the module to pair FOBs. To
understand pin names and functions please reference Module
Operation and Features (38246-01/38847-01) — Section 4.
There may be a push button attached to J13P2, if it is not supplied,
short J13P2 (learn pin) to J11P1 (12Volt pin) when it says “push
button”.
Note: Programming new FOBs will unlearn any programmed FOBs
previously stored. You may learn up to 50 FOBs. Make sure you have
all the FOBs that you wish to program before starting this process.
1. Press the push button 3 times within 5 seconds (more than 3 is
acceptable)
a. The system will send a pulse to lock and unlock the entry
door
b. Two LEDs (red and green) located near the dip switches will
remain on as long as the controller is in learn mode
2. Press and release a button (any button) on each FOB
a. The system will send a pulse to lock and unlock the entry
door
3. Wait 10 seconds
a. Entry door unlocks and you exit FOB learn mode
Panic Mode
Activating
The Panic Mode sequence is activated by pressing and holding for 2
seconds the panic button on the FOB. During Panic Mode, siren and
headlight outputs are used to draw attention to the vehicle. Panic mode
cannot be used if the parking brake is not active (vehicle in gear).
Deactivating
Panic time of 60 seconds expires
Unlock command from the FOB
Unlock from the keypad
Vehicle engine turns over
Parking brake inactive (vehicle in gear)
9
