TriMark 500-1300 e-ASK - J5-Relay Outputs 4-Pin; J11-Push to Start PKE 12-Pin

18
Pin Input/Output Function
J5P1 Output Keypad Ground
J5P2 (Unused Pin)
J5P3 Output
Keypad Power
12V regulated output
J5P4 (Unused Pin)
J5—Relay Outputs 4-Pin
Pin Input/Output Function
J11P1 Input
Vehicle Battery
Powers all ICs and relays on J11 connector.
J11P2 Input (+)
AUTH_REQ
Input to request PKS system to locate FOB.
J11P3 Output (Relay 20) (Not Assigned)
J11P4 Output (-)
AUTH_RESP
While AUTH_REQ is active, the I/O module will activate
this out if an authorized FOB is in range.
J11P5 Input (+)
Door Handle—Proximity Sense Input to request PKE
system to locate FOB
J11P6 Antenna
LF Antenna 1—Interior Area 1
Used to sense FOBs inside the vehicle cab.
J11P7 Output (Relay 20)
Door Lights
Activates to Power to turn on the vehicle exterior Door
Lights.
J11P8 Output (Relay 20) (Not Assigned)
J11P9 Signals
CAN Low
Connection to vehicle’s CAN bus.
J11P10 Signals
CAN High
Connection to vehicle’s CAN bus.
J11P11 Input Vehicle Ground
J11P12 Antenna
LF Antenna 1—Return path
Used to sense FOBs inside the vehicle cab.
J11—Push to Start PKE 12-Pin
