J13—Entry Door PKE 14-Pin
19
Pin Input/Output Function
J13P1 (Not Assigned)
J13P2 Input (+)
FOB Learn Mode Request
Using this input to program FOBs.
J13P3 Output (-) (Not Assigned)
J13P4 Output (-) (Not Assigned)
J13P5 Antenna
LF Antenna 2—Exterior
Used to sense FOBs exterior to the vehicle cab near the
door handle.
J13P6 (Unused Pin)
J13P7 (Unused Pin)
J13P8 Output
Door Handle Power
12V regulated power output for the door handle.
J13P9 Input (+)
Door Ajar
Activating this input indicates at lease one door is ajar.
J13P10 Input Vehicle Ground
J13P11 (Not Assigned)
J13P12 Antenna
LF Antenna 2—Return path
Used to sense FOBs exterior to the vehicle cab near the
door handle.
J13P13 Input Vehicle Ground
J13P14 Antenna
RF Antenna
Attached to a wire at least 40” long for HF communication
Dip Switch Settings
The dip switches are there to enable/disable any visual/audio functions
this controller provides. Dip switches are located next to the J3
connector
Dip Switch Function
1 Unassigned
2 Siren (J3P7)
3 Headlights (3P3)
4 Horn (J3P2)
