RS485 connection
Infinity – Operational Manual
11
B-
A+
A+ A+
B-B-
A+
B-
A+
B-
. . . . . . . . .
Upto 31 units on bus
without repeater
RS232 CABLE
RS485-RS232C
CONVERTER
