OR
KVAh = 120.12
(Display parameter as per the selected parameter in the programming
mode).
In Dual Source Meter instead of “KWh” it shows “EBKWh” for Electricity
Board Active Energy or “EBKVAh” for Electricity Board Apparent Energy.
Programming Mode
The Programming Mode is possible for user interface with settable
parameters such as CT-Primary and Meter Address for RS485 port and
display energy parameter. .
Setting CT-Primary
The CT-Primary is settable from 5 to 5000. The CT-Primary should be set to
give the actual value of KWh.
To set the CT-Primary, follow the instructions below:
1. In Run Mode, press key for about four seconds. The unit enters
into Programming Mode such as shown below.
CT_PRI=1550
Infinity – Operational Manual
13
PROG
ENTR
