2. Press key again. Immediately, P starts blinking which
indicates that the parameter can now be changed. Set the
parameter value by pressing and keys until the
desired value is received.
3. Press key to confirm the parameter value. Hence, the
unit will restart and return into Run Mode.
PROG
ENTR
PROG
ENTR
Setting Meter ID for RS485 port
The Unit has the provision to specify a meter ID at site for RS485
port. The address can be set starting from 1 to 255 with a fixed
baud rate of 9600. (This Baud rate can also be specified for 19200
at the time of ordering according to user's requirement).
To set the Meter ID, follow the instructions below:
1. In Run Mode, press key for about four seconds. The
unit enters into Programming Mode and press key till
Device ID is prompting such as shown below.
PROG
ENTR
DEVICE ID=2
14
Infinity – Operational Manual
