For providing resolution, KWh is multiplied with 100 before
transmitting. Thus if the KWh value is 278.99, it is sent out as
27899.
Based on selected display energy, only single type of energy data
will be available over RS485.
If an attempt is made to read from some address other than the
valid address, the exception response is sent.
EXCEPTION CODE:
In the event of the query from the HOST has no communication
error, but there is some error in specifying the address of registers
to be read, the meter returns an exception message. The format of
the exception message will be as under:
Unit address 0X83 Exception code CRC CRC
Exception code can have only one value 02 :
If the address is not a valid address or host has requested more
than 32 bytes data, this code is returned.
Infinity – Operational Manual
23
