5 Electrical and Physical distribution
5.1 Back Cabinet
1
st
Shelf
• Two (2) fans
• Transformer 120/240V
2
nd
Shelf (From left to right)
PSU 12VDC
• Four (4) Fans
• Two (2) Lighthouses
• One (1) Coin door
• Two (2) LED light assembly
PSU 24VDC
• 11.38m of LED strip
PSU 5VDC
• Fan control board
Terminal 12/24VDC & 120VAC (power source for the LED and Fans)
KCU Motion Controller
Two (2) Power bars (8 outlets)
1. Computer Server
2. Computer Client
3. PSU 5VDC
4. PSU 12VDC
5. PSU 24VDC
6. Amp PB425B50 and fan board
7. Seat
1. D-Box Controller
2. PSU Helmet HTC 1
3. PSU Helmet HTC 2
4. LED Tube
5.
Two (2) PSU for the two (2) HTC Helmet
I/O Board
Fan controller & PB425B50 board
Ampli PB415
