Triotech Storm VR - Replacing the Control Box

Maintenance and Repairs
Storm-OM-001
43
28 February 2020
This document, including the information contained herein, is proprietary to Triotech Amusement Inc.
10.2 Replacing the control Box
The system uses a S type
Actuator Control Module.
It is imperative to always replace
a control box by another one of
the same type.
Start the process by following steps 1 to 8 Remove
the cables, connectors and plates on both sides.
1- Remove the 8 hex screws using a
2.5mm allen key to remove the access
cover.
2- You can now remove the cover.
Remove the cables on the left of the
ACM.
