To install a new actuator, follow the same steps in reverse order. You should be
particularly aware of the following:
• Make sure to tie the cables back together (see picture Step 8).
• The white connector and the black connector of the right-hand actuator should be
connected on the right-hand side of the control box.
• The white connector and the black connector of the left-hand actuator should be
connected on the left-hand side of the control box. Do not cross cables or
connectors.
