7. Installation
7.5 Opening / Closing the Console
The console consists of two modules: an LCD module located under the top cover and a keyboard / touchpad module below
the LCD module. The modules can slide together or independently of one another. This allows the LCD to be available for
viewing while the keyboard / touchpad module is not in use.
7.5.1 Opening Separately
1. Release the console by sliding the front panel toward the center. Then engage the catches and pull the top panel 1-2
inches toward you. Once the console has been released, release the catches.
2. Pull the top panel all the way out until it clicks into place.
